Wire Range: Minimum .1773" (4.5mm) #6 AWG to
Maximum 1.379" (35mm) 1400 kcml


Universal Line Post Insulator

15KV - 28KV - 35KV - 46KV

This innovative product can be installed in either Vertical of Horizontal applications. Unique two-bolt design allows the traveller to be left in place while the keeper bolt can be tightened.

No more need to stock two types and bother with separate clamps. Now one product comes complete with integral clamp ranging from #6ACSR to 1400Kcmil.

For copper users it can also be purchased with aluminum body tin-plated. Made from Dow Corning silicone rubber it is designed for maximum sel-cleaning characteristics and long life performance.

Tested in independantly in Toronto by Kinectrics Lab to meet North American ANSI standards and CEA LWIWG stringent specifications.

Quality and Competitive Pyungil in use in the most demanding locations in North America and the Caribbean.

Standard Shipping Dimensions:

1. 15KV (Standard Box of 3) - Weight: 33 lbs - Box Dimensions: 16 x 22 x 8.5
2. 28KV (Standard Box of 3) - Weight: 36 lbs - Box Dimensions: 18 x 22 x 8.5
3. 35KV (Standard Box of 3) - Weight: 44 lbs - Box Dimensions: 22 x 22 x 8.5
4. 46KV (Standard Box of 3) - Weight: 47 lbs - Box Dimensions: 24 x 22 x 8.5
